Gasoline engine | Honda GX690(13kW) |
Fuel tank | 50L |
Hydraulic system | Danfoss |
Travel speed | 0-8km/h |
Max gradeability | 11° |
Air compressor | 0.18m³/min (0.8MPa) |
| Pump | 2 hydraulic plunger pumps |
Maximum flow rate | 9L × 2 |
Working pressure | 10-20MPa |
Spray gun | 2 automatic and 1 manual |
Spraying width | 50-600mm |
Paint tank | 190L |
Glass bead tank | 50L pressurized tank |
Hydraulic oil tank | 80L (drive system) |
Hydraulic oil tank | 12L（Hydraulic pump） |
Dimension(LWH) | 3000×1980×2300mm |
Net weight | 1100kg |
